Features
Transformer Power Source
Tried and tested technology, the transformer power source is simple, reliable, and long-lasting.
Made in Europe
Built in Europe, you can guarantee that you’re getting the highest level of quality and maximum performance from the machine.
4 Geared Wire Drive
The most consistent and smoothest wire-feeding experience there is. With a four geared wire drive unit, there’s more power pushing the wire, improving the wire feeding, especially in longer torches.
21 Voltage Steps
Get complete precision over your weld bead. With up to 21 voltage steps, you can adjust your weld in small increments so that it’s just right.
250mm Cooling Fan
Built to be durable, the large 250mm cooling fan with an enclosed motor maximises the cooling, increasing the duty cycle and keeping your machine going for longer.
Gas Check
The gas check ensures that your gas bottle is connected and that the gas pressure is dialled in to protect every weld.
Burnback
Stop your wire from ever fusing with your weld or your contact tips again. Tune your burnback control to suit how much wire you want to remain sticking out from your torch when you finish a weld.
Soft Start
Start a weld flawlessly with the soft start function. By slowing the initial burst of wire feeding, the weld pool is established without being explosive, improving the quality of the beginning of the weld.
Spot Mode
Get perfectly even tacks every time. Spot mode creates a series of consecutive and evenly timed arcs that work well if you want perfectly even tacks and small welds. Adjust your tacks exactly how you want them with the spot time and interval time settings.
Specifications
Primary Input Voltage
240V Single-Phase
Supply Plug
Unplugged (32A Recommended)
Ieff (A)
39.0
Protection Class
IP21
Insulation Class
F
Minimum Generator (kVA)
13.0
Dinse Connector
35/50
Standard
AS 60974.1
Warranty
3 Years
Weight (kg)
116.00
Dimensions (LxWxH)
870 x 940 x 460mm
Suitable Materials
MIG: Mild Steel, Stainless Steel, Aluminium, Silicon Bronze
Downloads
WORKSHOP 270 Manual
1.13 MB
