DC Lift Arc Start TIG
Lift Arc ignition allows the arc to be started easily in DC TIG by simply touching the tungsten to the workpiece and lifting it up to start the arc. This stops the tungsten tip sticking to the workpiece and breaking the tip from the tungsten electrode.
Inverter Technology
Not every inverter is made equal. With UNIMIG's ever-evolving, state-of-the-art IGBT Inverter technology, you get better performance, better efficiency, and better reliability.
10A Plug
Plug in and play. The 10A plug can be used on any domestic outlet, so it’s perfect for the DIY home handyman or the professional welder looking to take it anywhere.
Additional Features
Thermal Overload Protection
Integrated Thermal Overload Protection will kick in to prevent the machine from exceeding a safe operating temperature, keeping the internal components protected.
Voltage Reduction Device
The built in VRD function ensures your safety on every weld. Designed to switch on automatically when you stop welding, the VRD reduces the open circuit voltage (OCV) of the welder, keeping you protected whenever you're not welding.
Generator Compatible
Take it anywhere. Connect the machine to a generator and use it wherever, whenever you need it. We recommend an 8kVA for this machine.
Lightweight & Portable
Weighing just 4.0kg, the VIPER ARC 140 is ready to go anywhere you need it.
Specifications
Primary Input Voltage
240V Single-Phase
Supply Plug
10A
Ieff (A)
10.0
Imax (A)
26.0
No Load Voltage (V)
62.9
Protection Class
IP21S
Insulation Class
F
Minimum Generator (kVA)
8.0
Dinse Connector
10/25
Standard
AS 60974.1
Warranty
1 Year
Weight (kg)
4.00
Dimensions (LxWxH)
352 x 140 x 260mm
Suitable Materials
MMA: Mild Steel, Stainless Steel, Cast Iron
TIG: Mild Steel, Stainless Steel, Copper, Silicon Bronze
Downloads
VIPER ARC 140 Manual
4.12 MB
