Features
0.9-2.8mm Wire Size
Weld almost every wire size there is. This torch is capable of welding from 0.9mm up to 2.8mm filler wires.
500A Output
Perform effortlessly on every weld. With a rated output of up to 500 amps, it delivers superior performance.
Ergonomic Handle
The ergonomic handle provides comfort even during extended periods of usage.
Duraflex Performance Cable
Get ultimate cable flexibility and the highest heat and abrasion resistance. The outer cable jacket is constructed from cross-link polymers, providing a tear-proof layer with a burn threshold of 375°C.
Secure Housing & Support
The toughest, damage-resistant housing and nuts. Formed in robust glass-reinforced polymers, all of the conductive parts are housed and protected in accordance with EN60974-7, CE & CCC standards.
Specifications
Cooling Method
Air-Cooled
Maximum Output
500A
Duty Cycle @ 40°C - CO2
60% @ 500A
Duty Cycle @ 40°C - Mixed Gas
60% @ 400A
Wire Size
0.9-2.8mm
Lengths (m)
3.6, 4.5
Standard
EN 60974-7
Downloads
MIG Torch Manual
5.08 MB
