Features
0.8-2.0mm Wire Size
Weld almost every wire size there is. This torch is capable of welding from 0.8mm up to 2.0mm filler wires.
400A Output
400A Output Perform effortlessly on every weld. With a rated output of up to 400 amps, it delivers superior performance.
Ergonomic Handle
The ergonomic handle provides comfort even during extended periods of usage.
Duraflex Performance Cable
Get ultimate cable flexibility and the highest heat and abrasion resistance. The outer cable jacket is constructed from cross-link polymers, providing a tear-proof layer with a burn threshold of 375°C.
Secure Housing & Support
The toughest, damage-resistant housing and nuts. Formed in robust glass-reinforced polymers, all of the conductive parts are housed and protected in accordance with EN60974-7, CE & CCC standards.
Specifications
Cooling Method
Air-Cooled
Maximum Output
400A
Duty Cycle @ 40°C - CO2
60% @ 400A
Duty Cycle @ 40°C - Mixed Gas
60% @ 350A
Wire Size
0.8-2.0mm
Lengths (m)
3.6, 4.5
Standard
EN 60974-7
Downloads
Standard MIG Torch Manual
5.71 MB
TWC4 Tweco Style MIG Torch Info Sheet
0.57 MB
