Arc Torchology Technologies
Stay cooler for longer. A series of passages and wells are built into the consumables, effectively force-cooling the collet, maximising conductivity and extending consumable life.
18% Better Power-to-Weight Ratio
Get better performance than an 18 Series water-cooled torch in a torch the same size as a 17 Series.
Longer Consumable Life
Get superior life out of every consumable. Designed for maximum performance, you’ll get 20x longer life with Arc Torchology consumables.
The Arc Torchology ceramic cups lasted up to 5x longer, withstanding the maximum amperage for 200 hours vs the WP26's 40 hours.
Digital Control Module
The control pad lets you adjust your parameters while welding without disturbing the filler metal and weld puddle.
Customisable Controls
Weld the way you want to with a range of interchangeable torch potentiometers for every style.
Consumables For Every Occasion
Get consumables to match your welding requirements, no matter the application or environment.
A versatile all-rounder, the standard TIG consumables are a great choice for most welds.
Additional Features
Flex-Neck Torch Head
Bend your torch head to any angle you need. Arc Torchology torches come with a flexible torch head as standard, allowing you to access tight and cramped spaces when you need to.
Tested to Last
Arc Torchology cables undergo rigorous lab testing, enduring over 500,000 flex cycles to ensure maximum durability and long-lasting performance to withstand the toughest welding conditions.
Specifications
Cooling Method
Water-Cooled
Maximum Output
450A
Duty Cycle @ 40°C - DC
100% @ 450A
Duty Cycle @ 40°C - AC
100% @ 315A
Lengths (m)
4, 8
Tungsten Range
1.6-4.8mm
Dinse Size
35/50
Standard
EN 60974-7
Downloads
Arc Torchology TIG Torch Manual
3.01 MB
Arc Torchology Brochure
7.87 MB
T4W TIG Torch Info Sheet
0.82 MB
