Duraflex Performance Cable
Get ultimate cable flexibility and the highest heat and abrasion resistance. The outer cable jacket is constructed from cross-link polymers, providing a tear-proof layer with a burn threshold of 375°C.
Rear Cable Support
The extra-durable cable support system keeps your torch housing protected and intact no matter what angle the torch lead is bent at, improving wire-feeding consistency.
Additional Features
0.6-1.2mm Wire Size
Weld across almost the entire range of wire sizes with this torch, from as thin as 0.6mm to as thick as 1.2mm.
230A Output
Perform effortlessly on every weld. With a rated output of up to 230 amps, it delivers outstanding performance.
Patented Ergonomic Handle
Stay comfortable no matter how long the weld is. The ultimate combination of balance, positioning, and ergonomics, the screwless design and soft rubber grips provide comfort that feels custom-made.
Specifications
Cooling Method
Air-Cooled
Maximum Output
230A
Duty Cycle @ 40°C - CO2
60% @ 230A
Duty Cycle @ 40°C - Mixed Gas
60% @ 200A
Wire Size
0.6-1.2mm
Lengths (m)
3, 4, 5
Standard
EN 60974-7
Downloads
MIG Torch Manual
5.08 MB
