Cutting Capacity
Get a 12mm clean cut with the internal air and a 16mm clean cut using external air. Severance cut as thick as 14mm with the internal air and an 18mm severance cut using external air on mild steel.
Cutting Modes
Cut through solid metal plate on any material.
Inverter Technology
Not every inverter is made equal. With UNIMIG's ever-evolving, state-of-the-art IGBT Inverter technology, you get better performance, better efficiency, and better reliability.
Built-In Air Compressor
Ultimate flexibility and cut quality come together in one machine. The internal air compressor means you can use this machine anywhere without needing to attach an external component.
Pilot Arc Start
Start your arc on any surface: painted, greasy, or rusted, or don’t start on the surface at all. A pilot arc start will ignite the arc even from a short distance away, giving you better control and longer-lasting consumables.
Additional Features
Air Test
Check that your plasma cutter is running at peak performance. The air test ensures that your compressor is connected and that the air pressure is dialled in to produce the best cuts.
Generator compatible
Take it anywhere. Connect the machine to a generator and use it wherever, whenever you need it. We recommend 10kVA for this machine.
Specifications
Primary Input Voltage
240V Single-Phase
Supply Plug
15A
Ieff (A)
15.0
Imax (A)
30.0
No Load Voltage (V)
210.0
Protection Class
IP21
Insulation Class
H
Minimum Generator (kVA)
10.0
Dinse Connector
10/25
Standard
AS 60974.1
Warranty
3 Years
Dimensions (LxWxH)
610 x 215 x 420mm
Weight (kg)
18.00
Downloads
RAZOR CUT 40 AIR Manual
10.17 MB
