Feature Video
Maximum 1/1/1/1 Classification
Superior optical clarity with a 1/1/1/1 classification. This classification evaluates the clarity, light diffusion, shade and angle uniformity of a helmet's lens, ensuring the best visibility and minimal distortion for welders.
The optical class determines how distorted the image is through the lens. The image should be clear and crisp to obtain a 1 rating.
Auto Shade Select
Take the guesswork out of your protection. The auto shade select technology instantly detects the arc and decides what shade you need to keep your eyes safe for every kind of welding.
Advanced Sensor System
Detect every arc instantly. The four optimally positioned arc sensors, coupled with an arc intensity sensor, trigger the Auto-Darkening Filter. Experience unparalleled eye protection right from the start of every weld, even when you’re out of position.
External Grind Button
Seamlessly switch to grind mode with the click of a button. When the helmet is in grind mode a small LED will illuminate, so you don’t need to take the helmet off to check.
4 Point Harness
Get the perfect fit and stay comfortable for hours. Adjust all 4 points of contact to suit you, and have the weight spread more evenly, minimising neck strain.
Respirator-Compatible Design
Engineered to accommodate the Elipse® Half-Mask P2 Respirator, ensuring your lungs stay as protected as your eyes while you weld.
Additional Features
102.5x102.5mm View Size
Unmatched visibility in every situation. The 102.5x102.5mm viewing area lets you see every weld with complete clarity.
3.0 Light State
Get a clear view before and after the weld, as well as during. With a 3.0 light state, you’ll be able to see your workpiece as well with the helmet on as with it off.
Backup Battery
2 x CR2450 backup batteries improve the performance and reliability of the auto-darkening filter.
Specifications
Filter Dimensions
114x133x9.5mm
View Size
102.5x102.5mm
Arc Sensors
4 Arc Sensors, 1 Arc Intensity Sensor
Classification
1/1/1/1
Light State
3
Dark State
5-13
UV/IR Protection
DIN15
Time from Light to Dark
0.04ms
Time from Dark to Light
0.1-0.9s
Sensitivity Delay
Adjustable (1-5 for Low-High)
Power Supply
Solar Cells & CR2450 Replaceable Battery
Warranty
3 Years
Operating Temperature
-10˚C to 65˚C
Storage Temperature
-20˚C to 85˚C
Shade Control
Yes
Grind Mode
Yes (External)
Minimum TIG Amperage
2A
Standard
AS/NZS 1337.1 B (High Impact)
AS/NZS 1338.1 (Auto-Darkening)
Downloads
Professional Series Helmet Manual
2.34 MB
Welding Helmets Brochure
19.34 MB
