Maximum 1/1/1/1 Classification
Superior optical clarity with a 1/1/1/1 classification. This classification evaluates the clarity, light diffusion, shade and angle uniformity of a helmet's lens, ensuring the best visibility and minimal distortion for welders.
The optical class determines how distorted the image is through the lens. The image should be clear and crisp to obtain a 1 rating.
99.8% Filter Protection
Get fresh, clean air and breathe easy while you weld. The certified TH3 filtration has an inward leakage protection level of less than 0.2%, meaning 99.8% of fumes and particles are removed.
EliteVision Lens Technology
See your weld clearly in true colour. EliteVision technology allows more colours from the spectrum to pass through the view, giving you better optical clarity and reducing eye fatigue.
See the difference
External Grind Button
Seamlessly switch to grind mode with the click of a button. When the helmet is in grind mode a small LED will illuminate, so you don’t need to take the helmet off to check.
4 Arc Sensors
Detect every arc instantly. The four optimally positioned arc sensors trigger the lens, darkening it and keeping your eyes shielded from the start, even when you’re out of position.
Feature Video
Additional Features
Up to 8 Hours Battery
Work a full shift without charging up. The built-in 4400mAH lithium-ion battery gives you up to 8 hours of battery life on the lowest intensity, with quick and easy recharging of the power adapter. *Lasts up to 4 hours on the highest intensity.
100x83.4mm View Size
Superior visibility in every situation. The 100x84.3mm viewing area lets you see every weld with complete clarity.
Memory States
Store up to three of your most frequently used shade settings with the memory state buttons, and have your helmet ready to go in an instant.
Backup Battery
2 x CR2450 backup batteries improve the performance and reliability of the auto-darkening filter.
Specifications
Filter Dimensions
114x133x9.5mm
View Size
100x83.4mm
Arc Sensors
4
Dark State
5-13
UV/IR Protection
DIN15
Time from Light to Dark
0.08ms
Time from Dark to Light
0.1-0.9s
Sensitivity Delay
Adjustable (1-5 for Low-High)
Power Supply
Solar Cells & CR2450 Replaceable Battery
Warranty
2 Years
Operating Temperature
-10˚C to 65˚C
Storage Temperature
-20˚C to 85˚C
Shade Control
Yes
Grind Mode
Yes (External)
Standard
AS/NZS 1337.1 B (High Impact)
AS/NZS 1338.1 (Auto-Darkening)
Respiratory Protection Standard
AS/NZS 1716:2012
Downloads
PAPR Helmet Manual
5.50 MB
Lithium Ion PAPR Battery MSDS
0.23 MB
