Ultimate TIG Welding
Weld every kind of metal. With the ability to run on an Alternating Current (AC) you’re able to weld aluminium as effortlessly as mild and stainless steels on a Direct Current (DC).
Multiple AC Waveforms
Completely customise your aluminium welds. Switch between Sine, Square, Trapez and Triangle waves, or use a combination of the two, to change the arc characteristics, bead profile, and penetration to suit your weld.
Mixed AC/DC
Experience the best of both worlds. Mixed AC/DC combines the efficiency of AC and the penetration of DC- TIG in one weld. With it, you get faster welding speeds, better penetration, a faster weld puddle on cold workpieces, and you can weld on thicker materials.
Foot Pedal Ready
Enjoy greater control and precision with our optional foot control accessory. This handy feature allows you to easily adjust your TIG amperage on the fly, without interrupting your torch movement.
Additional Features
AC MIG
Get even more control over your aluminium MIG welds. The alternating current (AC) gives you the heat input and the cleaning action usually reserved for AC TIG.
AC MIG Welding Speed
Increase your efficiency with the advanced AC MIG Welding Speed. By setting the rate the wire is deposited during the negative portion of the AC cycle, you can adjust your welding speed while still maintaining your desired arc length.
Maximum AC TIG Amperage
Set the maximum current of the positive side of the AC cycle the machine can reach when TIG welding. By reducing the amperage of the positive portion of the cycle, the negative portion works to compensate, allowing for a more penetrative weld and reduced risk of the tungsten melting.
Specifications
Protection Class
IP23S
Insulation Class
H
Dinse Connector
35/50
Standard
AS 60974.1
Warranty
5 Years
Suitable Materials
MIG: Mild Steel, Stainless Steel, Aluminium, Silicon Bronze
TIG: Mild Steel, Stainless Steel, Aluminium, Copper, Silicon Bronze, Titanium, Magnesium, Zinc Alloys
