Ideal for Softer Wires
The perfect torch for welding softer metals, especially aluminium. The geared motor in the torch pulls the wire along, so it can be fed over much further distances, giving you more flexibility with your welds.
Maximum Visibility
See every moving part. Get a complete view through the clear plastic housing over the motor and internal components, so you can ensure your wire is feeding smoothly and consistently.
Additional Features
1.0-1.6mm Wire Size
Seamlessly weld the thicker wire sizes. This torch is capable of welding from 1.0mm up to 1.6mm filler wires.
400A Output
Perform effortlessly on every weld. With a rated output of up to 400 amps, it delivers superior performance.
3000+ Hours Motor Life
Engineered to last as long as your welder, the push-pull gun’s motor has over 3000 hours of run time.
Hydroflex Performance Cable
Get ultimate cable flexibility and the highest heat and abrasion resistance. The water-cooled cable system ensures an uninterrupted flow rate and delivery of coolants.
Rear Cable Support
The extra-durable cable support system keeps your torch housing protected and intact no matter what angle the torch lead is bent at, improving wire-feeding consistency.
Specifications
Cooling Method
Water-Cooled
Maximum Output
400A
Duty Cycle @ 40°C - CO2
100% @ 400A
Duty Cycle @ 40°C - Mixed Gas
100% @ 350A
Wire Size
1.0-1.6mm
Lengths (m)
8
Minimum Motor Life (Hours)
3000
Standard
EN 60974-7
Downloads
Push Pull & Spool Gun Manual
2.71 MB
