Features
0.8-1.6mm Wire Size
Weld almost every wire size there is, This torch is capable of welding from 0.8mm up to 1.6mm filler wires.
400A Output
Perform effortlessly on every weld. With up to a 400 amp output, there isn’t much this torch can’t weld.
Ergonomic Handle
The ergonomic handle provides comfort even during extended periods of usage.
Duraflex Performance Cable
Get ultimate cable flexibility and the highest heat and abrasion resistance. The outer cable jacket is constructed from cross-link polymers, providing a tear-proof layer with a burn threshold of 375°C.
Secure Housing & Support
The toughest, damage-resistant housing and nuts. Formed in robust glass-reinforced polymers, all of the conductive parts are housed and protected in accordance with EN60974-7, CE & CCC standards.
Specifications
Cooling Method
Air-Cooled
Maximum Output
400A
Duty Cycle @ 40°C - CO2
60% @ 400A
Duty Cycle @ 40°C - Mixed Gas
60% @ 320A
Wire Size
0.8-1.6mm
Lengths (m)
3.6, 4.5
Standard
EN 60974-7
Downloads
Standard MIG Torch Manual
5.71 MB
BND400 Bernard Style MIG Torch Info Sheet
0.49 MB
