Features
0.8-1.2mm Wire Size
Capable of welding a wide range of wire sizes, you’ll be able to use all the most common filler metals available.
300A Output
Perform effortlessly on every weld. With up to a 300 amp output, there isn’t much this torch can’t weld.
Ergonomic Handle
The ergonomic handle provides comfort even during extended periods of usage.
Duraflex Performance Cable
Get ultimate cable flexibility and the highest heat and abrasion resistance. The outer cable jacket is constructed from cross-link polymers, providing a tear-proof layer with a burn threshold of 375°C.
Secure Housing & Support
The toughest, damage-resistant housing and nuts. Formed in robust glass-reinforced polymers, all of the conductive parts are housed and protected in accordance with EN60974-7, CE & CCC standards.
Specifications
Cooling Method
Air-Cooled
Maximum Output
300A
Duty Cycle @ 40°C - CO2
60% @ 300A
Duty Cycle @ 40°C - Mixed Gas
60% @ 200A
Wire Size
0.8-1.2mm
Lengths (m)
3.6, 4.5
Standard
EN 60974-7
