VIPER 185 MIG/TIG/STICK Welder

$979.00

VIPER 185 MIG/TIG/STICK Welder

$979.00

The VIPER™ 185 is the ultimate multi-process welder for the DIY enthusiast. MIG, TIG or STICK, the VIPER™ does it all, and it’s ready to go anywhere you have a standard 10-amp outlet. Get repairs done and see your projects come together in record time with the ability to change modes with the flick of a switch.

The VIPER™ 185 is the perfect solution for those looking for insane performance without needing to blow your budget on multiple welders.

KUMJRVM185

FIND A STORE

ADD TO WISHLIST

10 AMP PLUG

Connect to any standard outlet.

SPOOL GUN READY

For softer wires, such as Aluminium.

VOLTAGE REDUCTION DEVICE

Prevents Voltage overloading, protecting yourself and the machine.

GEARED WIRE DRIVE

For smoother wire feeding.

Product No: KUMJRVM185

MACHINE SPECIFICATIONS

PRIMARY INPUT VOLTAGE

240V Single Phase

SUPPLY PLUG

10 AMP

RATED INPUT POWER (kVA)

7.1

Ieff (A)

9.8

RATED OUTPUT

30A/15.5V - 180A/23.0V

NO LOAD VOLTAGE (V)

PROTECTION CLASS

IP21S

INSULATION CLASS

POWER FACTOR

0.7

MINIMUM GENERATOR (kVA)

10.0

DINSE CONNECTOR

35/50

STANDARD

AS/NZ60974-1

SUITABLE MATERIAL

Mild Steel, Stainless Steel, Cast Iron, Silicon Bronze, Aluminium, Copper

WARRANTY (Years)

MIG Specifications

MIG WELDING CURRENT RANGE

30-180A

MIG DUTY CYCLE @ 40°C

10% @ 180A

MIG WIRE SIZE RANGE

0.6-0.9mm

MIG WIRE SPOOL SIZE

1kg / 5kg

MIG WELDING THICKNESS RANGE

1-10mm

DRIVE ROLLER SIZE

30/22

TIG SPECIFICATIONS

TIG FUNCTION TYPE

DC Lift Arc

TIG WELDING CURRENT RANGE

10-160A

TIG DUTY CYCLE @ 40°C

10% @ 160A

TIG WELDING THICKNESS RANGE

1-6mm

STICK SPECIFICATIONS

STICK WELDING CURRENT RANGE

10-160A

STICK DUTY CYCLE @ 40°C

10% @ 160A

STICK ELECTRODE RANGE

2.5-4.0mm

STICK WELDING THICKNESS RANGE

2-10mm

Size & Weight

DIMENSIONS (mm)

553x214x388mm

WEIGHT (kg)

12.0kg

MACHINE FEATURES

WIRE DRIVE

Geared

VRD

Yes

SPOOL GUN CONNECTION

Yes

BURNBACK ADJUSTMENT

Yes

WIRE INCH

Yes

THERMAL OVERLOAD PROTECTION

Yes

VIPER 185 MIG/TIG/STICK Welder
4m SB15 MIG Torch
3m Twist Lock Electrode Holder
300 Amp Earth Clamp & Lead
Twin Gauge Argon Regulator
2m Gas Hose Complete with fittings
Operating Manual

Here you’ll find the latest manuals, guides & product/parts information.

VIPER 185 Info Sheet

VIPER 185 Manual

UNIMIG is pleased to offer a 2 year warranty on the VIPER 185*.

UNIMIG offers warranty across Australia with four UNIMIG service centre’s in Sydney, Melbourne, Brisbane & Perth. We also have authorised service centres across Australia as well.UNIMIG’s focus is to assure the buyer is getting reliability, performance and peace of mind with a quality product.

UNIMIG also offers an additional 6 months warranty free of charge when you register your product online via the UNIMIG website.

*Please note warranty only applies to the power source only
