Smart-Set MIG
Getting set up for a weld has never been faster with our preset synergic programs. Simply select your wire size and material type and the machine does the rest, picking the optimal settings for your weld.
Multi-Process
Get the job done quickly and efficiently with our versatile three-in-one welding machine. With the ability to perform MIG, TIG, and MMA welding all in one unit, it's also capable of running both gas-shielded and gasless MIG wire, so you can tackle a wide variety of welding projects with ease. Whether you're working with mild steel, stainless steel, aluminium, or flux-cored wire, our machine has got you covered, saving you valuable time and effort without sacrificing quality.
Inverter Technology
Not every inverter is made equal. With UNIMIG's ever-evolving, state-of-the-art IGBT Inverter technology, you get better performance, better efficiency, and better reliability.
10A Plug
Plug in and play. The 10A plug can be used on any domestic outlet, so it’s perfect for the DIY home handyman or the professional welder looking to take it anywhere.
Additional Features
Generator Compatible
Take it anywhere. Connect the machine to a generator and use it wherever, whenever you need it. We recommend an 9kVA for this machine.
Lightweight & Portable
Weighing just 9.8kg, you can take this machine with you anywhere.
Specifications
Primary Input Voltage
240V Single-Phase
Power Supply
10A
Ieff (A)
10.0
Imax (A)
31.8
No Load Voltage (V)
64.0
No Load Voltage with VRD Active (V)
15.5
Protection Class
IP21S
Insulation Class
H
Minimum Generator (kVA)
9.0
Dinse Connector
35/50
Standard
AS 60974.1
Warranty
2 Years
Weight (kg)
9.80
Dimensions (LxWxH)
513 x 206 x 391mm
Suitable Materials
MIG: Mild Steel, Stainless Steel, Aluminium, Silicon Bronze
MMA: Mild Steel, Stainless Steel, Cast Iron
TIG: Mild Steel, Stainless Steel, Copper, Silicon Bronze
